Focal Length f: 8.25 mm ± 5 %
Aperture Range: F1.4–F16
Image Circle: 16 mm (1”)
Focus Range: 0.1 m to infinity
Optimum Working Distance: 1.0 m
Relative Illumination at Full Aperture: 36 %
Resolution (25 % MTF, Center, Full Aperture): Designed for 64 LP/mm
Optical Distortion: Typical -7.07 %
Angle of View, 1\: Horizontal: 79.66° Vertical: 62.92°
Angle of View, 1/1.2\: Horizontal: 72.3° Vertical: 47.85°
Wavelength Range: Visible (400–700 nm)
Pupil Magnification, ßP: 45.73
Chief Ray Angle, CRA: 5.6°
Front Focal Length, sF: 16.05 mm
Back Focal Length, sF: 11.65 mm
Principal Point Separation, HH: 41.62 mm
Entrance Pupil Position, sEP: 16.67 mm
Overall Optical Length, d: 74.17 mm
Flange Back: 17.526 mm
Mount: C-mount
Weight: Approx. 220 g
Focus/Iris Operation: Manual operating angle: 211.3°
