Interface: GigE
Measuring Method: Time-of-Flight
Resolution: 640px x 480px / VGA
Field of View (H x V): 67° x 51°
Range: Short: 0.3–1.5 m Long: 0.3–10 m
Accuracy (typical): ±5 mm (0.5–5.5 m)
Temporal Noise (typical): <1.0 mm (up to 5.5 m)
Frame Rate: 20 fps (Default)/ 30 fps (FastMode)
Latency: <85 ms
Synchronization: Free run, software trigger, hardware trigger
Housing Size (L x W x H): 34 mm x 56 mm x 62 mm
Illumination: VCSEL, 940 nm
Ambient Light Robustness: Ambient light: max. irradiance 12.8 W/m² @ 920–970 nm
Communication Interface: Gigabit Ethernet (1000 Mbit/s)
Pixel Formats: Depth Map: Coord3D_C16, Mono16, Coord3D_ABC32f/ Intensity Image: Mono16/ Confidence Map: Mono16, Confidence16/ Point Cloud: Coord3D_ABC32f
Camera Power Requirements: 24 VDC (±10 %) supplied via the camera
Size (W x H x L): 99.6 x 80.6 x 63.1 mm
Weight: <690 g
Software: pylon Camera Software Suite (version 6.2 or higher)/ pylon Supplementary Package for blaze
Operating System: Windows 10 Linux x86_64 (tested under Ubuntu 18.04, 20.04, and 22.04) Linux ARM
Programming Languages: C++, Visual Basic, C#, Python
Mono/Color: Mono
