Resolution (H x V Pixels): 4112 x 3008 (full resolution) 4096 x 3000 (default resolution)
Resolution: 8.9 MP
Sensor Type: Sony IMX255LLR Progressive scan CMOS
Sensor Format: 1.1 inch
Effective Sensor Diagonal: 17.6 mm
Pixel Size (H x V): 3.45 x 3.45 µm
Frame Rate (at Default Settings): 9.4 fps
Mono / Color: Mono
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger, Via software trigger, Via free run
Exposure Time Control: Via hardware trigger, Programmable via the camera API
Camera Power Requirements: ≈3.2 W (typical) when using Power over Ethernet, ≈2.7 W (typical) @ 12–24 VDC when supplied via, I/O connector
Lens Mount: C-mount
Size (ø x L): 50.0 x 40 x 30 mm (without lens mount or connectors) 61.8 x 40 x 30 mm (with lens mount and connectors)
Weight: <90 g
Conformity: CE (includes RoHS), EAC, UL Listed, FCC, GenICam, GigE Vision, IP30, IEEE 802.3af (PoE), REACH, KC
Software: Basler pylon Camera Software Suite (version 4.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
