Resolution (H x V Pixels): 2592 x 2048
Resolution: 5.3 MP
Sensor Type: onsemi PYTHON NOIP1SE5000A Progressive scan CMOS
Sensor Format: 1 inch
Effective Sensor Diagonal: 15.9 mm
Pixel Size (H x V): 4.8 x 4.8 μm
Frame Rate (at Default Settings): 21 fps (at fast sensor readout mode), 20 fps (at normal sensor readout mode)
Mono / Color: Color
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger, Via software trigger, Via free run
Exposure Time Control: Via hardware trigger, Programmable via the camera API
Camera Power Requirements: ≈3.9 W (typical), ≈4.1 W (max.) when using Power over Ethernet/ ≈3.4 W (typical), ≈3.6 W (max.) @ 12–24 VDC when supplied via I/O connector
Lens Mount: C-mount
Size (ø x L): 42.0 x 29 x 29 mm (without lens mount or connectors)/ 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
Conformity: CE (includes RoHS), EAC, UL Listed, FCC Class B, GenICam, GigE Vision, IP30, IEEE 802.3af (PoE), ISO 13485:2016, REACH, KC
Software: Basler pylon Camera Software Suite (version 4.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
