BalunTech BL672S Isothermal Blackbody Calibration Source (20℃~50℃)

Temperature range: 20°C to 50℃ (68F to 122F)

Effective aperture size: 65mm diameter

Emissivity: Better than 0.995

Cavity type: Isothermal blackbody cavity

Control stability: ± 0.05°C

Display resolution: 0.01°C

Blackbody uniformity: 0.05°C

Heat cavity shape: End closed tube

Heat up time: 10 minutes from ambient to 50℃

Heat up/Cool down time: 10 minutes from ambient to 20℃

Control method: Digital PID controller with readout

Temperature sensor: Class A Precision platinum RTD

Power supply: 110-220V AC 50Hz, 350WA

Interface: RS232

Dimension: 300mm(H)x 200mm(W)x 280mm(D)

Net weight: Approx. 9kg

SCOPE OF DELIVERY

BL672S Portable blackbody calibration source

Power adapter

User manual

Datasheet

With isothermal cavity, the BL672 is a portable blackbody calibration source utilizing a digital indicating temperature ambient 20℃ to 50℃ (68F to 122F). The 65 mm diameter end closed tube is heated or cooled with an internal solid state thermoelectric heat pump.   It has a built-in digital temperature controller to provide accurate, stable temperature as well as to provide readout.

FEATURE

The isothermal cavity

Better than 0.995 emissivity

65mm diameter aperture

0.05°C high stability

Calibrate from 20°C to 50°C

Built-in temperature correction function

Portable and easy operate

APPLICATION

Calibrate ear infrared thermometer

Calibrate forehead infrared thermometer

Calibrate thermal camera

Calibrate infrared screening instrument

Calibrate infrared sensor
