Size : DN15-DN300mm
Accuracy : ±1.5%(standard),±1.0%(optional)
Power Supply : 12VDC,24VDC
Communication : RS485/Modbus, Hart, Profitbus
Flange Standard : EN1092-1
- PN10,PN16,PN25,PN40
- ANSI BS16.5 Class 150,300,600
- JIS2220 10K,20K,40
- AS2129 Table D,Table E
- AS4087 PN16,PN21,PN35
Straight Pipe : Inlet Path ≥ 12D,Outlet Path ≥ 5D
Signal Output : 4~20 mA,pulse
Frequency Output : 2~3000 Hz
Relative Humidity : ≤85%
Explosion-proof : Exia IIC T6 Gb
Ambient Temperature :-40℃~55℃(Non Ex-proof Place)-20℃~55℃(Non Ex-proof Place)
Nominal Pressure : 1.6 MPa, 2.5 MPa, 4.0MPa
Protection Grade : IP65
Velocity :
- 0.4~7.0 m/s liquid
- 4.0~60 m/s gas
- 5.0~70 m/s steam
Body Material : SS304(Standard),SS316(Optional)
Resistance Coefficient : Cd ≤2.6
Oscillatory Acceleration: ≤0.2g
Reynolds Number : 2x10^4~7x10^6
Read the documentation carefully before ordering
