Input
Input range: 90 - 264 Vac (Operating); 115/230 Vac (Nominal) TERMINAL BLOCK
Frequency: 47 - 440 Hz, Nominal 50/60
Input current: 12 A RMS max input current, at 100 Vac
Output
Output rating: See table 1: 90 - 264 Vac
Rated load: 1000 W maximum. Derate linear to 50% from 50 °C to 70 °C
Minimum load: Main output @ 0.0 A; 5 Vsb @ 0.0 A. No loss of regulation
Operating temperature:-20 °C to 70 °C (with linear 50% derating from 50 to 70 °C)
Storage temperature: -40 °C to +85 °C
Humidity: 20 to 90%, non-condensing. Operating. Conformal coat option available.
Functions: Short circuit protection; Overload protection (OCP); Overvoltage protection (OVP); Overtemp protection
Ordering Information
Output: 48 V
Nominal Output Voltage Set Point: 48 V
Set Point Tolerance: ±0.5%
Adjustment Range: 40.8 - 52.8 V
Current
Min: 0 A
Max: 20.8 A
Output Ripple P/P (0-50°C): 480 mV
Max Continuous Power: 1000 W
Combined Line/ Load Regulation: 2%
