Input
Input range: 90 - 264 Vac / 164 - 320 Vdc
Frequency: 47 Hz to 63 Hz
Max input current： 11.7 Arms @ 90 Vac
Output
Main DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 11.9/ NOM: 12.0/ MAX: 12.1
Total output regulation range： MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 1/ MAX: 66.7 A
Standby DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 11.9/ NOM: 12.0/ MAX: 12.1
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0/ MAX: 3 A
Operating temperature: 0 to 55 °C, the maximum operating temperature (55 °C) is to be derated by 1 °C per 300 m above 2000 m
Operating humidity: +5% to +85% non-condensing
Storage temperature: -40 °C to +70 °C, non-condensing
Storage humidity: +5% to +95% non-condensing
Airflow: Normal fan
Nominal Output Voltage: 12.0 Vdc
Set Point: 11.9 - 12.1 Vdc
Regulation Band: 11.4 - 12.6 Vdc
Minimum Current: 1 A
Maximum Current: 66.7 A
Output Ripple P/P: 120 mV
Standby: 12.0 V @ 3 A
