Input range: 90 - 264 Vac / 180 - 300 Vdc
Frequency: 47 Hz to 63 Hz
Max input current: 8.5 Arms @ 180 Vac; 12.5 Arms @ 100 Vac
Main DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 12.1/ NOM: 12.2 / MAX: 12.3
Total output regulation range: MIN: 11.8 V/ MAX: 12.6 V
Output current: MIN: 1/ Hi line: 108.3 A ; Lo line: 83.3 A
Standby DC Output:
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 11.9/ NOM: 12.0/ MAX: 12.1
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0 A/ MAX: 3 A
Operating temperature: 0 to 55 °C
Operating humidity: +5% to +90% non-condensing
Storage temperature: -40 °C to +85 °C, non-condensing
Storage humidity: +5% to +95% non-condensing
Airflow: Normal fan
Nominal Output Voltage: 12.2 Vdc
Regulation Band: 11.6 - 12.6 Vdc
Minimum Current: 1 A
Maximum Current: Hi line: 108.3 A; Lo line: 83.3 A
Output Ripple P/P: 120 mV
Standby: 12.0 V @ 3 A
