Bearing design: Air, fine-pored carbon
Motor design: Electronically Commutated (EC) - Permanent Magnet Synchronous Motor
Displacement transducer design: High-resolution optical encoder
Working mode: Combined Motor Transducer (CMT)
Minimum torque (rotation): 5 nNm
Minimum torque (oscillation): 1 nNm
Maximum torque: 215 mNm
Minimum angular deflection (set value): 0.5 µrad
Maximum angular deflection (set value): ∞ µrad
Minimum angular velocity [1]: 0 rad/s
Maximum angular velocity: 314 rad/s
Maximum speed: 3000 1/min
Minimum speed (CSS/CSR): 10⁻⁷ 1/min
Minimum angular frequency [2]: 10⁻⁷ rad/s
Maximum angular frequency: 1256 rad/s
Maximum frequency [3]: 200 Hz
Normal force range: -50 to 50 N
Normal force sensitivity: 0.001 N
Minimum gap size change: 0.0625 µm
Dimensions (W x H x D): 453 x 725 x 673 mm
Weight: 48 kg
1. In controlled shear stress (CSS) mode. In controlled shear rate (CSR) mode, depending on measuring point duration and sampling rate.
2. Theoretical value (duration per cycle = 2 years)
3. Higher frequencies are possible using multi-wave functionality (942 rad/s (150 Hz) or even higher, depending on measuring system and sample)
4. Depending on used temperature device
