Measuring Range:
Dynamic viscosity: 0.2 mPa·s to 10,000 mPa·s
Shear rate : 0.5 s-1 to 1,000 s-1
Temperature: 5 °C to 100 °C (41 °F to 212 °F)
-40 °C to +100 °C (-40 °F to +212 °F) (with counter cooling)1)
Measuring Range:
Dynamic viscosity: 0.2 mPa·s to 10,000 mPa·s
Shear rate : 0.5 s-1 to 1,000 s-1
Temperature: 5 °C to 100 °C (41 °F to 212 °F)
-40 °C to +100 °C (-40 °F to +212 °F) (with counter cooling)1)
Test duration: Minimal 30 s, typical 3 min
Sample volume: 0.1 mL to 0.8 mL
Weight: 19.9 kg (43.9 lb)
Dimensions (L x W x H) : 526 mm x 420 mm x 230 mm (20.7 in x 17.2 in x 9 in)
Power supply : AC 100 V to 240 V; 50 Hz to 60 Hz; 190 VA
1) Specified temperatures are valid for a max. ambient temperature of 35 °C (95 °F). Lower measuring temperatures are achieved in lower ambient temperatures and/or with special equipment.
2) Verified with a 1.59 capillary at 70° angle and Ethanol 96 % at 20 °C using the same ball for all repeated measurements.
3) Verified with a 1.59 capillary with a single-point adjustment performed on site at 70° angle; adjustment and all measurements performed with distilled water at 20 °C with the same ball.
