Measuring range:
Density: 0 g/cm³ to 3 g/cm³
Pressure: 0 bar to 10 bar (0 psi to 145 psi)
Temperature: 15 °C to 60 °C (59 °F to 140 °F)
Repeatability, s.d.*: Density: 0.00005 g/cm³; Temperature: 0.02 °C (0.04 °F)
Reproducibility, s.d.*: Density: 0.00007 g/cm³
Accuracy**: Density: 0.0001 g/cm³
Digital Resolution: Density: 0.00001 g/cm³; Temperature: 0.01 °C (0.01 °F)
U-View™: Yes
FillingCheck™: Yes
Full-range viscosity correction: Yes
Minimum sample volume: Approx. 1 mL
Integrated tables and functions: Density, Specific Gravity (SG), alcohol tables, sugar/extract tables, various acid/base tables, API functions
Wetted parts: Borosilicate glass, PTFE
Dimensions (L x W x H): 375 mm x 265 mm x 180 mm (14.8 in x 10.4 in x 7.0 in)
Weight: 13.5 kg (29.8 lb)
Power supply: AC 100 to 240 V; 47 to 63 Hz; DC 24V, 3A
Display: 7 inches, TFT WVGA (800 x 480 Px); PCAP touchscreen
Controls: Touchscreen, optional keyboard, mouse, and bar code reader
Communication interfaces: 1 x Ethernet, 3 x USB, 1 x RS232
Internal storage: 5000 measured results; 400 products
Other special functions:
Integrated temperature and humidity sensor for intelligent condition monitoring
Built-in pressure sensor for adjustments
Quick one-point water adjustment
Menu language: English, German, Chinese, Czech, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish
Available options & upgrades:
Peristaltic pump
Printers
Aerosol filling adapter
Filling kit for pasty samples
ISO calibration
AP Connect lab execution software
Scope of supply: Compact density meter, power supply, power cable, waste vessel, accessory kit (including syringes, hoses, adapters), instruction manual
