IP Rating: IP20
Application: Server, Telecommunication, Other Devices up to 600 VDC
For Use With: Higher Voltage Power Distribution Systems
Current Rating: 40 A
Mounting Angle: Straight
Mounting Style: Panel Mount
Voltage Rating: 400 VAC/DC, 600 VAC/DC
Wire Gauge Max: 12 AWG
Wire Gauge Min: 18 AWG
Housing Material: Polycarbonate (PC)
Wire Gauge Range: 18 AWG to 12 AWG
Termination Style: Solder
Flammability Rating: UL 94 V-0
Housing / Hood Size: 40.7 mm x 26.6 mm x 19.7 mm
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 20 C
