Technology: GaAs
IF Frequency: DC to 20 GHz
LO Frequency: 18 GHz to 55 GHz
RF Frequency: 18 GHz to 55 GHz
Mounting Style: SMD/SMT
Development Kit: ADMV1555-EVALZ
Conversion Loss - Max: 8 dB
Pd - Power Dissipation: 342 mW
P1dB - Compression Point: 15 dBm
OIP3 - Third Order Intercept: 23 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
