Technology: GaAs
IF Frequency: DC to 8 GHz
LO Frequency: 22 GHz to 38 GHz
RF Frequency: 22 GHz to 38 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 14 dB
Conversion Loss - Max: 14.5 dB
Pd - Power Dissipation: 382 mW
P1dB - Compression Point: 13.5 dBm
OIP3 - Third Order Intercept: 21 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
