Pitch: 2.54 mm (0.1 in)
Application: Wire-to-Board
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 3 g
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder
Mating Post Length: 5.85 mm (0.23 in)
Number of Positions: 20 Position
Insulation Resistance: 10 GOhms
Termination Post Length: 3.05 mm (0.12 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 65 C
