Pitch: 2.54 mm (0.1 in)
Application: Board-to-Board
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 3.531 g
Housing Color: Black
Latching Type: Ejection
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 14 Position
Insulation Resistance: 5 GOhms
Termination Post Length: 3.43 mm (0.135 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 65 C
