Pitch: 5.08 mm
REACH - SVHC: Details
Current Rating: 17.5 A
Mounting Angle: 35 deg
Mounting Style: PCB Mount
Voltage Rating: 300 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 30 AWG
Contact Plating: Tin
Contact Material: Brass
Housing Material: Polyamide (PA)
Wire Gauge Range: 30 AWG to 12 AWG
Wire Orientation: 35 deg
Connection Method: Screw Clamp
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 11 Position
