Color: Black
Pitch: 7 mm (0.276 in)
Width: 31 mm
Gender: Plug (Male)
Height: 32.8 mm
Length: 32.8 mm
Application: Wire to Wire
Contact Gender: Without Socket Contacts
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 48 VDC
Housing Material: Polybutylene Terephthalate (PBT)
Locking Mechanism: On the terminal
Termination Style: Crimp
Ingress Protection: IP69K
Number of Positions: 4 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
