WEIGHT (kg): 70 kg ( Notice : This value is changeable relying on vacuum pump type)
BODY: Stainless Steel
SEALING BAR LENGTH (mm): 800 (option : 450,600, double heat wire)
SEALING BAR WIDTH (mm): 5, 10
VACUUM PUMP: Ejector vacuum pump type, oil vacuum pump, oilless vacuum pump
(Refer to selection method of vacuum pump)
REQUIRED ELECTRICITY: 1ph, 220V, 50/60Hz (Option : 110V)
REQUIRED AIR PRESSURE: 5-7kg/㎠
Max. instantaneous consumed electricity: 1.8 ~ 4.0 KW ( relying on sealing bar's length and width)
MAX. FINAL VACUUM: generally 85Kpa in case of using ejector type vacuum pump
VACUUM CREATION: timer controlled / vacuum sensor controlled
GAS FLUSHING/SEALING/COOLING: timer controlled
VACUUM VISUALISATION: appears digitally on LCD panel of control box
RECOMMENDED FOR: when a user needs a sub-stand on which the machine is put
PROCESS SETTING: The control unit memorizes various combinations of vacuum, gas flush & seal among MODE 1 ~ 8, besides S mode for only seal and V mode for only vacuum & seal.
ACCESSORIES ( FREE OF CHARGE )
1) SPARE PARTS - HEAT WIRE, TEFLON SHEET, FUSE
2) TOOLS - WRENCH SET, SPANNER, DRIVER
3) OTHERS - WORK trAY, TOOL BOX
