Bandwidth（-3dB）: 200Hz~120kHz
Maximum output voltage: 1020Vrms
Input voltage at full output: 1Vrms（1kHz）
Maximum output power: 1000VA
Input resistance: 10kΩ
Current monitor: 100mV/A
Voltage monitor: 10mV/ V
Total harmonic distortion （THD）: ≤1%@1kHz，100Vp-p
Output Connector :4mm Banana socket
Fault lights: Over current
Signal Ground: Floated to the same level as the source
Supply voltage: AC220V±10%，50Hz
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80%RH，no condensation
Size (W * H * D): 440*290*565mm
Output impedance: 30Ω, 115Ω, 260Ω, 460Ω, 720Ω, 1040Ω
Maximum output voltage: 170Vrms, 340Vrms, 510Vrms, 680Vrms, 850Vrms, 1020Vrms
Maximumoutput current: 5.67Arms, 2.96Arms, 1.96Arms, 1.48Arms, 1.18Arms, 0.98Arms
