Bandwidth（-3dB）: 200Hz~120kHz
Maximum output voltage: 848Vrms
Input voltage at full output: 1Vrms（1kHz）
Maximum output power: 400VA
Input resistance: 10kΩ
Current monitor: 100mV/A
Voltage monitor: 10mV/ V
Total harmonic distortion （THD）: ≤1%@1kHz，100Vp-p
Output Connector :4mm Banana socket
Fault lights: Over current
Signal Ground: Floated to the same level as the source
Supply voltage: AC220V±10%，50Hz
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80%RH，no condensation
Size (W * H * D): 440*290*565mm
Output impedance: 28 Ω, 112.4Ω, 253Ω, 449Ω, 702Ω, 1011Ω, 1376Ω, 1797Ω
Maximum output voltage: 106Vrms, 212Vrms, 318Vrms, 424Vrms, 530Vrms, 636Vrms, 742Vrms, 848Vrms
Maximumoutput current: 3.79Arms, 1.89Arms, 1.26Arms, 0.94Arms, 0.75Arms, 0.63Arms, 0.54Arms, 0.47Arms
