No. of Channel: 1
Form of Output: single-ended output
Bandwidth（-3dB）: DC~5kHz
Max. Output Voltage: 10kVp-p（±5kVp）
Max. Output Current: 10mAp（DC~50Hz）
20mAp（>50Hz）
Max. Output Power: 100Wp
Fuse: 4A/250V
Voltage Gain: x0~2000（1 step/10 step）
Upper Limit of Load RL: ≥495kΩ（DC~50Hz）
≥245kΩ（>50Hz）
Output Resistance: 5kΩ, 200kΩ switchable
Input Resistance: 10kΩ
Input Amplitude: 0~10Vp-pMAX
Output Voltage Error: ≤±3%@(DC，5kV)
Voltage Monitor: 1000:1
Slew Rate: ≥111V/μs
（THD）: ≤1%@1kHz，1kVp-p
Zero Drift of Output: ≤±1V
Output Connector: high voltage connector
Protection: over current protection
Signal Ground: connected to the case and power line
Supply Voltage AC: 220V±10%，50Hz
Operating Temperature: 0°C ~ 45°C
Storage Temperature: -20°C ~ 50°C
Humidity: ≤ 80% RH，no condensation
Dimension: 440*290*565mm (w * h * d)
