Output form: Single output
Bandwidth（-3dB）: DC~500kHz
Maximum output voltage: 310Vp-p(±155Vp)
Maximum output current: 0.5Ap(DC-50Hz, 1.41Ap，1Arms （50Hz~500kHz)
Maximum output power: 218.55Wp
Fuse: 8A/250V
Voltage gain: x0~100(0.1step)
Load RL upper limit: ≥109.6Ω (above 50Hz)
Output impedance: 1Ω＋3.2uH
Slew Rate: 400V/μs
DC bias: ±150V(0.1Vstep)
Input impedance: 50Ω / 5kΩ
Input amplitude: 0~10Vp-pMAX
Output voltage error: ≤±3%FS@1kHz
Voltage monitoring: 100:1（±5%）
Total harmonic distortion （THD）: ≤0.1%@1kHZ，100Vp-p
Output voltage zero-point drift: ≤0.1V
Output Connector: 4mm Banana socket
Protection: Overcurrent protection
Signal Ground: It is connected with the grounding of the shell and the power line
Supply voltage: AC220V±10%，50Hz
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80% RH，no condensation
Size(W * H * D): 440*163*470mm
