No. Of Channel: 1
Form of Output: Single-ended output
Bandwidth（-3dB）: DC~1.2MHz
Max. Output Voltage: 160Vp-p（±80Vp）
Max. Output Current: 0.5Ap（ DC~50Hz）
1.41Ap（ ＞ 50Hz）
Max. Output Power: 112.8Wp
Fuse: 5A/250V
Voltage Gain: x0~50（0.1 step/1 step）
Upper Limit of Load RL: ≥159Ω（DC~50Hz）
≥55.7Ω（＞50Hz）
Slew Rate: ≥426V/μs
DC Offset: ±75V（0.1V step/1V step）
Output Impedance: 1Ω+2μH
Input Resistance: 50Ω / 10kΩ
Input Amplitude: 0~10Vp-pMAX
Output Voltage Error: ≤±3%FS@1kHz
Voltage Monitor: 20mV/V
Current Monitor: 1V/A
THD: ≤0.1%@1kHz，100Vp-p
Zero Drift of Output Voltage: ≤±0.1V
Signal-noise ratio (SNR): ≥80dB
Output Connector: 4mm banana connector
Protection: Over current protection
Signal Ground: Connected to the case and power line
Supply Voltage: AC110~240V，50/60Hz
Operating Temperature: 0°C ~ 45°C
Storage Temperature: -20°C ~ 50°C
Humidity: ≤80% RH，no condensation
Dimension: 440*163*470mm (w * h * d)
