Number of channels: 2
Output form: Single output
Bandwidth（-3dB）: DC~200kHz
Maximum output voltage: 800Vp-p（±400Vp
Maximum output current: 40mAp
Maximum output power: 16Wp
Voltage gain: x0~120（0.1 step）
Load RL upper limit: ≥10kΩ
Output resistance: 100Ω /5kΩ (Customizable）
Slew Rate: 400V/μs
Input resistance: 50Ω / 5kΩ
Input amplitude: 0~10Vp-pMAX
Output voltage error: ≤±3% FS@1kHz
Voltage monitoring: 100:1（±5%）
Total harmonic distortion （THD）: ≤0.1%@1kHz，100Vp-p
Output voltage zero-point drift: ≤0.3V
Signal-noise ratio(SNR): ≥80dB
Output Connector: 4mm Banana socket
Protection: Overcurrent protection
Signal Ground: It is connected with the grounding of the shell and the power line
Supply voltage: AC220V±10%，50Hz
Fuse: 2A/250V
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: 80%RH，no condensation
Size (W * H * D): 365*163*365mm
