Number of channels: 1
Output form: Single output
Bandwidth（-3dB）: DC~1MHz
Maximum output voltage: 200Vp-p（±100Vp
Maximum output current :500mAp
Maximum output power: 50Wp
Fuse: 2A/250V
Voltage gain :x0~60（0.1 step）
Load RL upper limit: ≥200Ω
Output resistance: 5Ω /1kΩ (Customizable)
Input resistance :50Ω / 5kΩ
Input amplitude :0~10Vp-pMAX
Output voltage error: ≤±3% FS@1kHz
Voltage monitoring :100:1（±5%）
Slew Rate :500V/μs
Total harmonic distortion （THD）: ≤0.1%@1kHz，100Vp-p
Output voltage Zero-point drift :≤0.1V
Signal-noise ratio(SNR) :≥80dB
Output Connector: 4mm Banana socket
Protection :Overcurrent protection
Signal Ground: It is connected with the grounding of the shell and the power line
Supply voltage: AC220V±10%，50Hz
Operating temperature :0℃~45℃
Storage temperature :-20℃~50℃
Humidity: ≤80%RH，No condensation
Size (W * H * D): 365*163*365mm
