Output form: Differential output
Bandwidth (-3dB): DC~21MHz
Maximum output voltage: 60Vp-p (±30Vp)
Maximum output current:
500mAp (DC~50Hz)
1Ap (50Hz~21MHz)
Maximum output power: 30Wp
Voltage gain: 26dB adjustable (0.5dBstep)
Load RL upper limit: ≥30Ω (above 50Hz)
Slew Rate: 2800V/μs
Output resistance: 2Ω/ 100Ω
Input resistance: 50Ω / 1MΩ
Input amplitude: 0~10Vp-pMAX
Output voltage error: ≤±3%FS@1kHz
Total harmonic distortion (THD): ≤0.1%@1kHz，30Vp-p
Output voltage zero-point drift: ≤0.1V
Signal-noise ratio (SNR): ≥80dB
Output Connector: BNC、4mm Banana socket
Protection: Overcurrent protection
Signal Ground: It is connected with the grounding of the shell and the power line
Supply voltage: AC220V±10%，50Hz
Fuse: 1A/250V
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80%RH，no condensation
Size (W * H * D): 262*163*365mm
