Relative Pressure (R)(Zero At Atmospheric Pressure) : 0.3 - 0.4 - 0.5 – 1 – 2 - 3.5 - 5 bar 7.5 – 10 – 15 – 20 bar
Linearity And Hysteresis : ≤ ± 0.10 %
Temperature Effect (1°C):
a) on zero: ≤ ± 0.015%
b) on sensitivity: ≤ ± 0.015%
Nominal Sensitivity: 4-20mA (2 wires)
Calibration Tolerance: ≤ ± 0.1%
Nominal Power Supply: 11.5 - 24Vdc
Max. Power Supply: 28Vdc
Max. Absorption:: 20mA
Loading Resistance:: from 0 to 470Ω
Insulation Resistance: >2 GΩ
Zero Balance: ≤ ± 1%
Response Frequency: 0.5 KHz
Limit Mechanical Values Referred To Nominal Pressure::
a) service pressure: 100%
b) max. permissible pressure: 150%
c) breaking pressure: >300%
d) highly dynamic pressure: 75%
Reference Temperature: +23°C
Working Temperature Range: -10/+50°C
Storage Temperature Range: -20/+70°C
Protection Class (En 60529): IP68 (100h at 100m water column)
Sensor And Body Execution Material: AISI 316L
Protective Cap Material: POM Resina acetalica/ Acetal
Electrical Connection: Cable
