Measuring range: Standard value setting range; test current
100mΩ: 5.00mΩ~109.00mΩ; 100mA
1Ω: 0.0500Ω~1.0900Ω; 100mA
10Ω: 0.500Ω~10.900Ω; 30mA
100Ω: 5.00Ω~109.00Ω; 10mA
1kΩ: 0.0500kΩ~1.0900kΩ; 3mA
10kΩ: 0.500kΩ~10.900kΩ; 0.5mA
100kΩ: 5.00kΩ~109.00kΩ; 50μA
1MΩ: 0.0500MΩ~1.0900MΩ; 5μA
10MΩ: 0.500MΩ~10.900MΩ; 0.5μA
100MΩ: 5.00MΩ~109.00MΩ; 0.05μA
Test terminal open voltage: Below 14V
Measurement completion signal (EOC) pulse width: 1～250msec. or continuative
Measuring method: 2 or 4 terminal measurement capable of switching
Determination value setting range: %measurement:-99.99〜+25.00%, absolute value measurement: 00000～12500
Operation condition Temp.：0℃～+50℃、 Humidity：below 80%
Power supply: AC85V～265V、50～60Hz、about50VA
Outer dimension: 250(W)×92(H)×300(D)mm（excluding protruding parts such as rubber legs）
Weight: About 2.7kg
Option:
- External control/O、RS-232C、 Centronics standard
- GP-IB
- LAN
- Bar code unit（reader sold separately）
- Data transfer cable
- Short termination ( Zero ohm standard resistor)
