- Temperature Range: 0 ~ 170°C (32 ~ 338°F)
- Temperature Uncertainty:
Radiometric Calibration (standard): ±1°C @ 8 ~ 14 μm
Thermometric Calibration (optional): ±0.05°C
- Display Accuracy vs. NIST Calibration:
Radiometric Calibration (standard): ±1°C
Thermometric Calibration (optional): ±0.05°C @ calibration points
- Temperature Resolution: 0.01°C
- Stability: 0.05°C per 8-hour period in still air environment
- Source Non-Uniformity: ±0.15°C (excluding 10% border area) up to 50°C, ±0.75°C @ 150°C
- Heated Cavity Shape: Thermally uniform plate
- Exit Port Diameter: 152 mm x 152 mm (6" x 6")
- Emissivity ε:
Radiometric calibration (standard): 1.00 effective emissivity @ 8 ~ 14 μm
Thermometric Calibration (optional): @ 8 ~ 15 μm: 0.9756 ±0.0039 and @ 3 ~ 5 μm: 0.9713 ±0.0049
- Calibration Method:
Radiometric (standard)
Thermometric (optional, must be requested at time of order)
- Temperature Sensor: Precision platinum RTD 1/3 DIN
- Warm-up Time: ~15 min from ambient to 100°C
- Slew Rate to 1°C Stability:
~15° per min 25°C < T < 100°C
~11° per min 100°C < T < 170°C
~9° per min 0°C < T < 10°C
- Slew Rate to 0.1°C Stability: ~10 min for a Δ 10°C setpoint change
Environmental
- Operating Ambient Temp: 15 ~ 30°C (59 ~ 86°F)
- Cooling: Fan cooled, air inlet/outlet on top panel
- Operating Humidity: Dew point must be lower than blackbody setpoint
- Dimensions (H x W x D):
Blackbody: 279.4 mm x 254 mm x 381 mm (11" x 10" x 15")
Controller: 195 mm x 432 mm x 576 mm (7.67" x 17" x 22.66")
- Method of Mounting: Bench
- Weight:
Blackbody: 13.1 kg (29 lbs)
Controller: 15.5 kg (34 lbs)
- CE Certified: Yes
Communication and Electrical Specifications
- Remote Set Point: RS232
- Method of Control: Digital PID controller
- Power Requirements: 230 VAC @ 50 and 60 Hz
Accessory
Option: Serial Communication Output RS485
