- Temperature Range: 0 ~ 900°C (32 ~ 1652°F) (MB 9)
- 3 fixed optics:
100 mm, 300 mm, 800 mm
- IR Detector: Thermopile
- Spectral Range: 8 ~ 14 μm
- Emissivity ε: 0.2 ~ 1.0 adjustable
- Measurement Uncertainty Tamb (ε =1, t90 = 1 s):
T = -32 ~ 0°C: 1.5°C (Tamb = 15 ~ 30°C); 2°C (Tamb = 0 ~ 15°C or 30 ~ 63°C)
T = 0 ~ 300 °C: 0.6% of reading in °C or 1°C (Tamb = 15 ~ 30°C); 1% of reading in °C or 1.5°C (Tamb = 0 ~ 15°C or 30 ~ 63°C)
T = 300 ~ 900°C: 1% of reading in °C (Tamb = 15 ~ 30°C); 1.3 % of reading in °C (Tamb = 0 ~ 15°C or 30 ~ 63°C)
- Repeatability (ε =1, t90 = 1 s): 0.3% of reading in °C or 0.6°C
- Noise Equivalent Temperature Difference (NETD) (ε =1, tamb = 23°C ):
@ t90 = 80 ms: 0.2°C (@ 23°C measuring temperature)
@ t90 = 1 s: 0.05°C (@ 23°C measuring temperature)
- Optics: Germanium (Ge)
Electrical:
- Power Supply: 24 VDC (10 ~ 30 V)
- Power Consumption: Max 20 mA
- Load (analog output:) Max 700 Ω @ 24 V (max 100 Ω @ 12 V)
Interface and Communication:
- Analog Output: 4 ~ 20 mA (linear)
- Response Time t90: 0.08 s; adjustable in the pyrometer: 0.5 s, 1 s, 2 s, 5 s
Environmental
- Protection system: IP 65 (DIN 40050)
- Ambient Temperature: 0 ~ 70°C (32 ~ 158°F)
- Storage Temperature: -20 ~70°C (-4 ~ 158°F)
- Housing: Stainless steel
- Weight: Approx 410 g (~0.90 lbs)
- CE Label: According to EU directives about electromagnetical immunity
- Scope of Delivery: Pyrometer with selected optic, works certificate, operation manual
