Range / Measuring range / Resolution
3μA / 0.0nA～ 2999.9nA / 100pA
30μA / 0.000μA～ 29.999μA / 1nA
300μA / 0.00μA～ 299.99μA / 10nA
3mA / 0.0μA～ 2999.9μA / 100nA
30mA / 0.000mA～ 29.999mA / 1μA
300mA / 0.00mA～ 299.99mA / 10μA
Accuracy: within ±0.1％±5digit [Measuring time: AC1]
Display: －999～＋29999
Sampling time
[Free running mode] about 3 times per second～5 times per second [Slow], about 5 times per second～10 times per second [Fast]
[Remote start mode] about (9.5msec.＋Mmsec.＋Contact-Check Time)
Mfast : Available to set 1～99msec. or AC1 ACn: Power Line Freq, 60Hz＝16.7msec.×n MSLOW: Available to set AC1～AC9 Power Line Freq, 50Hz＝20.0msec.×n
Contact-Check Time: about 5msec.
Comparator set range: 00000～29999 both HI and LO
Indication of comparator's comparison result: LED indication LO/GO/HI and buzzer
Timer set: 000.00～999.99sec.
Control signal
Input: START (Remote start): "L" [OV] →"H" [DC12V]
HOLD (Remote hold): Open or "H" [DC12V] ：Free run/ "L" [OV] ：Hold
Output: LO/GO/HI (comparison)
CE (contact error)
EOC (end comparison)
Open collector: 40V/100mA (max.)
Operation condition: [Temp.] ＋5*C～＋40*C [Humidity] less than 85％
Power supply: AC100V～240V selectable, 50/60Hz、about 20VA
Outer dimension: about 333 (W) ×99 (H) ×300 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 4.5kg
