Measuring range and Accuracy (at23*C±5*C) *D<0.5 parallel equivalent circuit
Range/ Measuring range/ Measuring voltage/ Accuracy
0/ 10pF～ 99.9pF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
1/ 100pF～ 990pF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
2/ 1nF～ 9.99nF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
3/ 10nF～ 99.9nF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
4/ 100nF～ 999nF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
5/ 1μF～9.99μF/ about 1V (r.m.s.)/ within ±0.25％±0.25pF±1digit
Test signal: within 1kHz ±0.1%, SINE wave
C offset range: about 10pF
Decision time ＋ measurement: [Remote start mode] about 10msec.
Sampling time: [Free running mode] 50 times/sec.
Measured value display range: ±99.9％
External bias: max.DC25V
Comparator set range:
upper limit：＋0.0％～＋99.9％
lower limit：－0.0％～－99.9％
Indication of comparator's comparison result: LED indication -NG, GO, +NG and buzzer
Control signal:
Remote start input："L" [OV] →"H" [DC12V] start
Remote hold input：Open and "H" [DC12V]
：Free run/"L" [OV] ：Hold
comparison output [－NG/GO/＋NG]：open collector：max.50V, 100mA
end of comparison output [EOC]：open collector：max.50V, 100mA
BCD parallel output of measured value [BCD] ：fan out 2
Printing command signal：fan out 2
Operation condition [Temp.]: ＋5*C～＋40*C [Humidity] less than 85％
Power supply: AC100V～240V selectable, 50/60Hz, about 20VA
Outer dimension: about 260(W)×90(H)×250(D)mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 2.6kg
