Measuring range and Accuracy (at 23*C±5*C)
HV-deviation value measurement
Range / Measuring range / Measuring voltage / Measuring Accuracy
100kΩ / 5.00kΩ～ 150.00kΩ / 15V / ±0.03％±1digit
1MΩ / 50.0kΩ～ 1500.0kΩ / 15V / ±0.03％±1digit
10MΩ / 0.500MΩ～15.000MΩ / 15V / ±0.03％±1digit
100MΩ / 5.00MΩ～150.00MΩ / 100V / ±0.05％±1digit
1GΩ / 50.0MΩ～1500.0MΩ / 100V / ±0.05％±1digit
10GΩ / 0.500GΩ～ 15.000GΩ / 100V / ±0.2％±1digit
100GΩ / 5.00GΩ～ 150.00GΩ / 200V / ±0.5％±2digit
200GΩ (1000GΩ) / 50.00GΩ～300.00GΩ (300.01GΩ～1500.0GΩ) / 200V
HV-absolute value measurement
Range / Measuring range / Measuring voltage / Measuring Accuracy
100kΩ / 5.00kΩ～ 150.00kΩ / 15V / ±0.1％ of rdg ±1digit
1MΩ / 50.0kΩ～ 1500.0kΩ / 15V / ±0.1％ of rdg ±1digit
10MΩ / 0.500MΩ～15.000MΩ / 15V / ±0.1％ of rdg ±1digit
100MΩ / 5.00MΩ～150.00MΩ / 100V / ±0.2％ of rdg ±1digit
1GΩ / 50.0MΩ～1500.0MΩ / 100V / ±0.2％ of rdg ±1digit
10GΩ / 0.500GΩ～ 15.000GΩ / 100V/ ±0.5％ of rdg ±1digit
100GΩ / 5.00GΩ～ 150.00GΩ / 200V / ±0.8％ of rdg ±2digit
200GΩ (1000GΩ) / 50.00GΩ～300.00GΩ (300.01GΩ～1500.0GΩ / 200V / ±1.5％ of rdg ±4digit
LV-deviation value measurement
Range / Measuring range / Measuring voltage / Measuring Accuracy
100kΩ / 5.00kΩ～ 150.00kΩ / 15V /±0.03％±1digit
1MΩ / 50.0kΩ～ 1500.0kΩ / 15V / ±0.03％±1digit
10MΩ / 0.500MΩ～15.000MΩ / 15V / ±0.03％±1digit
100MΩ / 5.00MΩ～150.00MΩ / 15V / ±0.3％±1digit
1GΩ / 50.0MΩ～1500.0MΩ / 15V / ±0.3％±1digit
10GΩ / 0.500GΩ～ 15.000GΩ / 15V / ±1.2％±2digit
100GΩ / 5.00GΩ～ 150.00GΩ / 15V / ±1.5％±2digit
200GΩ (1000GΩ): NOT available
LV-absolute value measurement
Range / Measuring range / Measuring voltage / Measuring Accuracy
100kΩ / 5.00kΩ～ 150.00kΩ / 15V / ±0.1％of rdg±1digit
1MΩ / 50.0kΩ～ 1500.0kΩ / 15V / ±0.1％of rdg±1digit
10MΩ / 0.500MΩ～15.000MΩ / 15V / ±0.1％of rdg±1digit
100MΩ / 5.00MΩ～150.00MΩ / 15V / ±1.2％of rdg±1digit
1GΩ / 50.0MΩ～1500.0MΩ / 15V / ±1.2％of rdg±1digit
10GΩ / 0.500GΩ～ 15.000GΩ / 15V / ±1.5％of rdg±1digit
100GΩ / 5.00GΩ～ 150.00GΩ / 15V / ±2.0％of rdg±1digit
200GΩ (1000GΩ) :NOT available
Indication range: ±50.00％
Measuring method: 2 terminal measurement
Measuring time: (Measurement start signal be given after stable condition, after measured thing connection.) Integral Fast：1msec～29msec (setting possible with 1msec step)
Slow：50Hz:20.0msec×(1～9)cycle (setting possible with 1 cycle step) max.180msec 60Hz:16.7msec×(1～9)cycle (setting possible with 1 cycle step) max.150.3msec
Free run：about 33 time/sec～about 4 time/sec
Measuring delay time: 0 msec～99msec setting possible every range
Comparator: Both upper and lower limit：±0.00%～±50.00% LO,GO,HI judgment indication ＋ output
Control signal: (DC12V photo isolation power inclusion)
Outside hold input：0-12V signal and open short
Outside start input：0-12V signal and open short (Logic switching possibility) Judgment result output：Open correct output LO, GO, HI
Warm up time: More than 30 minutes
Others: Zero, Full scale calibration function by panel face operation RS-232C interface are built-in as standard equipment.
Power supply: AC100V～AC240V, Automatic selectable type, 50/60Hz
Outer dimension: about 333 (W) ×99 (H) ×300 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 4kg
