Measuring range (at23℃±5℃)
Range Measuring range Resolution Measuring current
1mΩ 0.0000mΩ～1.5000mΩ 0.1μΩ 3A
10mΩ 0.000mΩ～15.000mΩ 1μΩ 1A
100mΩ 0.00mΩ～150.00mΩ 10μΩ 1A
1Ω 0.0000Ω～1.5000Ω 100μΩ 100mA
10Ω 0.000Ω～15.000Ω 1mΩ 100mA
100Ω 0.00Ω～150.00Ω 10mΩ 10mA
1kΩ 0.0Ω～ 1.5000kΩ 100mΩ 1mA
％ 0.5mΩ～1kΩ/±50.00％ 0.01％ [50nΩ] refer to the above
Accuracy [Slow] within
±(0.01％rdg＋1μΩ)
±3digit [Average]
±4digit [Slow]
±5digit [Fast]
Open-circuit voltage of measuring terminal: about 4V
Measuring method: 4-terminal measurement [contact check available]
Sampling time:
[Free running mode] 2～10 times per second
[Remote start mode] about 16.5msec./ 29.8msec.
Setting range for comparator: Upper limit, lower limit for both [0～15000],
% range：50.00％ [low：0～－50.00％, high：0～＋50.00％]
Indication of comparator's comparison result: LED indication LO/GO/HI and buzzer
Control signal
Remote start input："L" [OV] →"H" [DC12V] start
Remote hold input：Open and "H" [DC12V]：Free run / "L" [OV]：Hold
Comparison output [LO/GO/HI]：open collector：max.40V, 100mA
Contact error output [CE]：open collector：max.40V, 100mA
End of comparison output [EOC]：open collector：max.40V, 100mA
Operation condition: [Temp.] ＋5℃～＋40℃ [Humidity] less than 85％
Power supply: AC100V～240V selectable, 50/60Hz, about 60VA
Outer dimension: about 333 (W) ×99 (H) ×300 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 3.8kg
