Direct access to our certified experts
Pressure range: -14.5 to 1,000 psi (-0.95 to 70 bar)
Control stability: 0.003% FS (stability based on % FS of control sensor range)
Precision(includes 1 year stability): See pressure range table
1 Year stability: 0.01% FS standard accuracy sensors
0.005% FS precision accuracy sensors
Media Clean: gas
Over-range indication: 103% to 120% (based on sensor)
Resolution: 4, 5, 6, or 7 digits (user selectable)[2]
Pressure type: Gauge, Absolute
Warm up time 15 minutes
Typical pressure settling time(within 0.003%FS): 20 seconds (10%FS pressure change assuming 50 mL test volume)
Measurement units: Pa, hPa, kPa, MPa, bar, mbar, psi, mmHg@0°C,cmHg@0°C, mHg@0°C, inHg@0°C,inH2O@4°C, mmH2O@4°C, cmH2O@4°C, mH2O@4°C, mmH2O@20°C, cmH2O@20°C,mH2O@20°C, kg/m2, kg/cm2, mtorr, torr, atm, lb/ft2, tsi, user selectable
Minimum control pressure[3] 0.0001 psi
