Integrating Sphere Size: Φ40mm
Light Source: Combined full spectrum LED light source, UV light source
Spectrophotometric Mode: Flat Grating
Sensor: Silicon photodiode array (double row 40 groups)
Wavelength Range: 400~700nm
Wavelength Interval: 10nm
Semiband Width: 10nm
Measured Reflectance Range: 0-200%
Measuring Aperture: Customized one aperture: MAV:Φ8mm/Φ10mm；SAV:Φ4mm/Φ5mm
Dimension: L*W*H=129X76X217mm
Weight: Approx 600g
Battery: Li-ion battery, 6000 measurements within 8 hours
Illuminant Life Span: 5 years, more than 3 million times measurements
Displayed Data: 3.5-inch TFT color LCD, Capacitive Touch Screen
Data Port: USB
Data Storage: Standard 1000 Pcs, Sample 20000 Pcs
Operating Environment: 0~40℃, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment: -20~50℃, 0~85%RH (no condensing)
Standard Accessory: Power Adapter, User Guide, PC Software(Download from office website), USB cable, White and Black Calibration Cavity, Protective Cover, Wrist strap, 8mm flat aperture, 8mm tip aperture, 4mm flat aperture, 4mm tip aperture
Optional Accessory: Micro Printer, Powder Test Box
