- Technical Parameters:
Contact discharge: 200 V – 30,000 V （±5%）
Air discharge: 200 V – 30,000 V （±5%）
Voltage step: 100 V
Hold time: ＞ 5 s
Polarity: Positive, negative
RC module recognition: Automatic recognition &LCD display
Temperature and humidity: Built-in temperature and humidity meter with functions of record and protection
Repetition frequency: Single /0.1/0.2/0.5/1/2/5/10/20 Hz
Trigger mode: Manual/automatic
Pulse Counter: 1-9999
Contact discharge: 150pF/330 ohm
Rise time: 0.8 ns +/- 25%
Quick start test program: Simple and easy to reset data online
Evaluate procedure: Contact discharge test at 20 Hz，evaluate the test points of DUT
Standard Test Procedure: accord with EN/IEC61000-4-2
- General Parameters:
Weight : Approx. 12.0 kg
Weight (EDS gun): Approx. 2.0 kg
Temperature: 15 ℃-35 ℃（operation condition）
Humidity: 30%-60%（operation condition）
Air pressure: 86 kPa-106 kPa
Working power supply: 100 V - 240 V（±10%）; 50/60 Hz（default AC 220 V 50 Hz for China Mainland）
